BDS 6 Inch Lift Kit | 2016-2023 Toyota Tacoma 4WD | w/ FOX 2.0 Performance Series Rear Shocks

This configuration includes FOX 2.0 Performance Series IFP rear shocks. FOX 2.0 shocks feature a 2-inch impact extruded aluminum body with an internal floating piston (IFP) monotube design, a massive 5/8-inch hard chrome plated heat-treated alloy steel shaft, CNC machined 6061-T6 aluminum mounting ends, race-developed high-flow piston design, application-specific valving, and a long-lasting clear anodized finish.

Overview

BDS Suspension offers a 6-inch suspension lift kit for 2016–2023 Toyota Tacoma 4WD trucks, designed to improve stance, performance, and off-road capability with clearance for up to 35-inch tires. Up front, the kit utilizes top-mounted strut spacers, high-arched 1/4-inch thick steel crossmembers, multipiece differential relocation brackets, and heavy-duty skid plates for off-road protection. Steering geometry is corrected at the new ride height using CNC-machined ductile iron steering knuckles that work with factory tie rod ends to maintain ESC system compatibility. Sway bar drops, bump stop extensions, brake line brackets, lower control arm cams, and all necessary hardware are also included. The rear of the kit uses heavy-duty cast steel lift blocks, brake line brackets, and longer U-bolts, rounded out with a rear shock option to suit your performance needs.

Features

• High-clearance crossmember design maximizes ground clearance using 1/4-inch thick laser-cut steel
• Robust CNC-machined ductile cast iron steering knuckles maintain proper steering angles and ESC system compliance
• Heavy-duty skid plate system improves off-road protection and bolts together to create a rigid subframe
• Multipoint differential relocation brackets secure the front axle and improve CV angles
• Heavy-duty cast steel rear lift blocks and longer U-bolts
• Factory Protection Plus drivetrain warranty included

Specifications

• Lift Height: 6 inches
• Tire Clearance: Up to 35 inches
• Compatible Vehicles: 2016–2023 Toyota Tacoma 4WD (also compatible with 2WD PreRunner models)
• Front crossmembers: 1/4-inch thick laser-cut high-arched steel
• Steering knuckles: CNC-machined ductile cast iron, compatible with factory tie rod ends
• Rear lift blocks: Heavy-duty cast steel

Installation

• Estimated Time: 4–5 hours
• Difficulty: Moderate
• Required Tools: Reciprocating saw, welding equipment, strut compressor

Important Notes

• Will not work on TRD Pro models
• Minor welding required
• Requires frame bracket modification
• Strut compressor required for installation
• Stock wheels cannot be reinstalled
• System will work on 2WD PreRunner models
• Cannot use 17-inch wheels
• FOX Shocks required for 2013–2020 models
