BDS Recoil Traction Bar Kit | 2020-2026 Chevy Silverado & GMC Sierra 2500HD/3500HD Long Bed

Overview

The BDS Recoil Traction Bar Kit is designed for 2020–2026 Chevy Silverado and GMC Sierra 2500 HD/3500 HD long bed models. Built with heavy wall construction and internal compression springs, this kit controls axle wrap without limiting wheel travel. The full float design delivers bind-free performance across the full range of suspension articulation and is compatible with a range of lift heights. Fabricated from 2-inch OD x 3/16-inch wall steel tubing, the bar features a threaded bung welded toward the axle end and a CNC-machined frame end. The axle mount uses BDS's large-forged flex end and jam nut, with a forged housing, large 1-1/4-inch x 12 threaded shank, single-sided snap ring, and 1-piece flex ball capable of up to 15 degrees of misalignment in either direction. At the frame end, a durometer-specific polyurethane bushing free floats within the traction bar via dual-stage internal compression springs and UHMW polyurethane bearings.

Features

• Adjustable axle wrap control using dual-stage resistance springs
• Full floating traction bar design will not bind throughout the full range of wheel travel or hinder suspension articulation
• Spring preload can be adjusted on the vehicle without disassembling the traction bar
• Traction bar ends are greaseable and rebuildable
• Mounting brackets are bolt-on, only requiring minor drilling for frame mount installation

Specifications

• Tubing: 2-inch OD x 3/16-inch wall steel
• Frame end: CNC-machined with durometer-specific polyurethane bushing and UHMW polyurethane bearings
• Axle end: Large-forged flex end with jam nut; forged housing with 1-1/4-inch x 12 threaded shank
• Flex ball: 1-piece, capable of up to 15 degrees of misalignment in either direction
• Internal springs: Dual-stage compression springs

Installation

• Estimated Installation Time: 3–4 hours
• Installation Difficulty: Moderately Easy
• Note: Minor drilling required for frame mount installation

Important Notes

• Does NOT fit Dually models
• Will ONLY fit crew cab long bed (8 ft)
• Will NOT fit standard cab, extended cab, or models with 6.5 ft beds
