BDS 2 Inch Leveling Kit | FOX 2.0 Snap Ring Strut & HD UCAs | 2021-2026 Ford F150 4WD | Without UCA Headlight Sensor

Select this option if your 2021–2026 Ford F150 does not have a UCA-mounted adaptive headlight sensor. This kit is configured for trucks without that sensor component.

Overview

This 2-inch leveling kit for the 2021–2026 Ford F150 4WD combines FOX 2.0 Performance Series coilover struts with heavy-duty upper control arms (UCAs). The kit is designed as a bolt-in upgrade that accepts up to 35x12.50 tires while delivering improved damper performance on- and off-road. The FOX 2.0 struts replace the factory strut assemblies while retaining the OE coil spring and top plate. The included HD UCAs are engineered for increased strength, greater suspension travel, and corrected ball joint positioning on leveled and lifted trucks.

Features

• FOX 2.0 Performance Series coilover struts deliver improved damper performance over the factory units
• Heavy-duty upper control arms increase strength and allow for more suspension travel
• FOX 2.0 Performance Series IFP rear shocks included
• Three preload settings provide a choice of 0", 1", or 2" of lift
• FOX 2.0 struts feature a 2.0" extruded and machined 6061-T6 aluminum body for improved heat dispersion
• Internal floating piston (IFP) eliminates oil aeration for consistent damper performance
• FOX proprietary internals and 5/8" hard chrome plated, heat-treated alloy shaft
• UCAs use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup for corrected ball joint positioning, additional down travel, and camber adjustment
• Durometer-specific rubber bushings at frame mounting ends for maintenance-free operation
• Greaseable ball joints at the knuckle end for smooth, quiet operation and superior durability
• UCAs finished in durable black powder coat with billet aluminum dust cap

Specifications

• Lift Height: 0", 1", or 2" (selectable via preload settings)
• Compatible Tire Size: Up to 35x12.50
• Strut body: 2.0" extruded and machined 6061-T6 aluminum
• Shaft: 5/8" hard chrome plated, heat-treated alloy
• UCA tubing: 1.5" OD x .120-wall
• UCA finish: Black powder coat
• Vehicle Fitment: 2021–2026 Ford F150 4WD

Installation

• Estimated Time: 3 hours
• Difficulty: Moderate
• Special Tools Required: Ball Joint Separation Tool, Strut Compressor
