BDS 3.5 Inch Lift Kit | FOX 3.0 Factory Race Series Internal Bypass Coil-Overs | 2025-2026 Chevy Silverado & GMC Sierra 1500 4WD

Overview

This 3.5-inch lift kit for the 2025–2026 Chevy Silverado and GMC Sierra 1500 4WD pairs BDS Suspension engineering with FOX Factory Race Series 3.0 internal bypass coil-over shocks to improve stance, performance, and off-road capability. The kit provides clearance for up to 35-inch tires on Silverado models and up to 33-inch tires on Sierra models. Up front, FOX 3.0 Factory Race Series internal bypass remote reservoir coil-over shocks are paired with heavy-duty tubular upper control arms for increased strength and suspension travel. In the rear, fabricated steel lift blocks, longer U-bolts, and a complementary set of FOX 3.0 Factory Race Series shocks deliver a smooth and balanced ride.

Features

• Builds off factory suspension geometry for improved performance with straightforward installation
• Front FOX 3.0 Factory Race Series internal bypass (IBP) coil-overs for high-performance damping with adjustable settings
• Rear FOX 3.0 Factory Race Series IBP shocks for improved ride quality, performance, and capability
• BDS HD upper control arms constructed from 1.5" OD x .120-wall tubular steel for strength and increased suspension travel
• Indexed ball joint cup corrects ball joint positioning for additional down travel and camber adjustment
• High misalignment angle, greaseable heavy-duty ball joints for smooth, quiet operation and superior durability
• Durometer-specific rubber control arm bushings at frame mounting ends for maintenance-free operation
• Arms finished in durable black powder coat with billet aluminum dust cap
• Rear lift block kit produces a level to slightly tail-high stance
• 1/4" wheel spacer included for use with spare tire if needed
• Optional weld-on steering stops available to improve tire clearance (dependent on wheel offset selected)
• Factory Protection Plus included

FOX Factory Race Series 3.0 Internal Bypass Technology

FOX Factory Race Series 3.0 Internal Bypass shocks deliver position-sensitive damping technology, Dual Speed Compression (DSC) adjustment, and high-speed-ready performance. Patented internal bypass technology allows multiple zones of damping control, producing a comfortable and confident ride with increased damping force through rough terrain. Bypass shocks provide progressive force to control hard bottom-outs, prevent harsh top-outs, and deliver an initial catch on landing. Finned external reservoirs and aluminum shock bodies manage fluid temperatures for consistent performance. Type III anodization protects the 3-inch diameter bodies against corrosion and wear. The DSC adjuster allows tuning for load, environment, and driving style.

Specifications

• Lift Height: 2–3.5"
• Front Lift Method: Coil-Over
• Front Lift Height: 3.5"
• Rear Lift Method: Block
• Rear Lift Height: 2.5"
• Shocks Included: Yes

Installation

• Estimated Installation Time: 4–5 hours
• Difficulty: Moderate
• Tools Required: Cut-Off Wheel or Equivalent, Ball Joint Separation Tool, Welding Equipment

Important Notes

• Fits 4WD models only.
• 5.5" maximum wheel backspacing.
• Will not fit models equipped with Adaptive Ride Control (ARC).
• Will fit Trail Boss/AT4 models; however, will net approximately 1.5" of lift over factory ride height.
• This kit has not been test fit on Silverado ZR2 or Sierra AT4X models.
• Lifting of the bed is required for shock installation.
• Will NOT fit models with a single leaf spring (monoleaf) rear suspension.
