BDS 2 Inch Leveling Kit | FOX 2.0 Coilover & HD Upper Control Arms | 2013-2018 Ram 1500 4WD

Overview

This 2-inch leveling kit from BDS Suspension is designed for 2013–2018 RAM 1500 4WD trucks. It levels the factory stance and improves both on- and off-road ride quality using FOX 2.0 Performance Series coilover shocks up front and matching FOX 2.0 Performance Series shocks in the rear. The kit also includes heavy-duty tubular upper control arms for increased strength and suspension travel, with clearance for up to 33-inch tires. All components are designed for a 100% bolt-on installation.

Features

• FOX 2.0 Performance Series coilover struts — improved damper performance over factory, direct bolt-in replacement for the factory strut
• FOX 2.0 Performance Series IFP rear shocks included for a smooth, matched ride front and rear
• Heavy-duty upper control arms (UCAs) increase strength and allow for more suspension travel
• UCAs use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup to correct ball joint positioning, enabling additional down travel and camber adjustment
• Frame mounting ends feature durometer-specific rubber bushings for maintenance-free operation
• Greaseable ball joint at the knuckle end for smooth, quiet operation and superior durability
• UCAs finished in durable black powder coat with a billet aluminum dust cap
• Factory Protection Plus drivetrain warranty included
• 100% bolt-on installation — no cutting or welding required

Specifications

• Front Lift Method: Coilover
• Front Lift Height: 2"
• Rear Lift Method: Stock
• Rear Lift Height: 0"
• Lift Height Range: 2"–3.5"
• Shocks Included: Yes
• FOX 2.0 coilover body: 2.0" extruded and machined 6061-T6 aluminum for improved heat dispersion
• Internal Floating Piston (IFP) design eliminates oil aeration
• Shaft: 5/8" hard-chrome-plated, heat-treated alloy
• Coilovers come preloaded with springs and top plate for easy installation
• Tire clearance: up to 33"

Installation

• Estimated Installation Time: 3–4 hours
• Installation Difficulty: Easy

Important Notes

• The stock wheel/tire can be reinstalled. Stock wheels with wider 12.50-inch tires cannot be reinstalled due to clearance issues with the UCA at full steering lock.
• Vehicles equipped with the Offroad or Rebel Package will not achieve the full 2" of lift; net ride height change will be approximately 1" above stock.
• Will not fit models equipped with adjustable air suspension.
