4 Inch Lift Kit | Ram 3500 4WD (2013-2018) Gas | 2 Inch Rear Block Kit w/ FOX 2.0 Adventure Series Shocks | Zone Offroad

This configuration includes a 2 Inch Rear Block Kit for a level-to-tail-high appearance and FOX 2.0 Adventure Series shocks featuring a nitrogen-charged twin-tube design, 10-stage velocity-sensitive valving, dual-welded ends, self-lubricating seals, and a 2-inch diameter steel body with black powder coat finish.

Overview

This 4-inch lift kit from Zone Offroad is designed for the 2013–2018 Ram 3500 4WD equipped with a 6.4L gas engine. The kit includes full-length coil springs, radius arm relocation brackets, steering correction components, and rear lift blocks to level the stance. It provides clearance for up to 37-inch tires.

Features

• Progressive rate front coil springs to improve ride quality and off-road performance
• Radius arm drop brackets to correct caster and improve suspension geometry
• Forged pitman arm and track bar relocation bracket to correct steering angles and recenter the front axle
• Extended bump stops, sway bar relocation, and brake line relocation to maintain factory-like operating angles
• Replacement rear lift blocks and u-bolts to lift and level the stance

Specifications

• Front Lift Method: Coil Spring & Drop Bracket
• Front Lift Height: 4 inches
• Rear Lift Method: Block
• Shocks Included: Yes
• Tire Clearance: Up to 37 inches

Installation

• Estimated Time: 5 hours
• Difficulty: Moderate
• Special Tools Required: Cut-off Tool, Pitman Arm Puller

Important Notes

• Fits trucks equipped with the 6.4L gas engine only.
• Front drive-line vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6-bolt transfer case use part #D5623. Models with an 8-bolt transfer case use part #D5813.
• Does NOT work for models with factory rear airbag suspension.
• Two-piece rear drive shaft: Add a carrier bearing drop kit to reduce post-lift driveline angles and avoid/eliminate driveshaft vibration.
• 6.4L Gas models will require exhaust modification to clear the front driveshaft.
• 5.7L Gas models may require modification.
• Factory wheels fit when paired with factory/original equipment tire size.
