3 Inch Adventure Series Lift Kit | 2015-2020 Ford F150 4WD | Strut Spacer Front / Nitro Series Rear | Zone Offroad

Configured with a Strut Spacer front lift method (3" lift) and Nitro Series rear gas shocks with a 1" rear block lift. Shocks included.

Overview

The Zone Offroad 3" Adventure Series Lift Kit for the 2015–2020 Ford F150 4WD is designed to go beyond a standard leveling kit. Working with the factory suspension mounting points, this kit improves ground clearance, creates room for larger tires, and enhances overall truck capability without requiring a full 4" or 6" suspension system.

Features

• High-strength UCAs are boxed and fully welded, with an indexed ball joint cup to correct ball joint operating angle for improved suspension travel
• Combination top-mount and preload strut spacers correctly lift the vehicle while retaining factory ride quality without over-extending suspension or drivelines at full droop
• Maintains ride and handling characteristics with clearance for larger tires
• 2" replacement rear lift blocks and heavy-duty U-bolts to level the stance
• Optional Nitro Series gas or FOX 2.0 Adventure Series gas rear shocks available to improve performance

Specifications

• Nitro Series shock features: Nitrogen-charged twin-tube design, 10-stage velocity-sensitive valving, dual-welded ends for increased strength, self-lubricating seals, black powder coat finish, 2-inch diameter steel body
• FOX 2.0 Adventure Series shock features: Internal floating piston (IFP) monotube design, large 5/8-inch hard chrome plated heat-treated alloy steel shaft, race-developed high-flow piston design, application-specific valving, long-lasting clear anodized finish

Installation

• Estimated Time: 3–4 hours
• Difficulty: Moderate
• Note: A strut compressor is required for installation

Important Notes

• Preload ring may not work with aftermarket struts; designed to be used with OEM struts
• Strut compressor required for installation
• Will fit EcoBoost models
• Will fit diesel models, but may result in a lower ride height
• Will NOT fit Raptor models
• Maximum 5.5" backspacing wheels recommended due to wheel/tire clearance to the UCAs
• This kit will not work on trucks with a stock ride height over 22". FX4, Snow Prep, and other off-road packages may have a stock ride height over 22"
