3 Inch Adventure Series Lift Kit | 2015-2020 Ford F150 4WD | Loaded Strut Front / Nitro Series Rear | Zone Offroad

Configured with a Loaded Strut front replacement (3" lift) and Nitro Series rear gas shocks with a 2" rear block lift. Provides an adjustable lift range of 2"–3.5". Shocks included.

Overview

The Zone Offroad 3" Adventure Series Lift Kit for the 2015–2020 Ford F150 4WD is designed to go beyond a standard leveling kit. Working with the factory suspension mounting points, this kit improves ground clearance, creates room for larger tires, and enhances overall truck capability without requiring a full 4" or 6" suspension system.

Features

• High-strength UCAs are boxed and fully welded, with an indexed ball joint cup to correct ball joint operating angle for improved suspension travel
• Combination top-mount and preload strut spacers correctly lift the vehicle while retaining factory ride quality without over-extending suspension or drivelines at full droop
• Maintains ride and handling characteristics with clearance for larger tires
• 2" replacement rear lift blocks and heavy-duty U-bolts to level the stance
• Optional Nitro Series gas or FOX 2.0 Adventure Series gas rear shocks available to improve performance

Specifications

• Nitro Series shock features: Nitrogen-charged twin-tube design, 10-stage velocity-sensitive valving, dual-welded ends for increased strength, self-lubricating seals, black powder coat finish, 2-inch diameter steel body
• FOX 2.0 Adventure Series shock features: Internal floating piston (IFP) monotube design, large 5/8-inch hard chrome plated heat-treated alloy steel shaft, race-developed high-flow piston design, application-specific valving, long-lasting clear anodized finish

Installation

• Estimated Time: 3–4 hours
• Difficulty: Moderate
• Note: A strut compressor is required for installation

Important Notes

• Preload ring may not work with aftermarket struts; designed to be used with OEM struts
• Strut compressor required for installation
• Will fit EcoBoost models
• Will fit diesel models, but may result in a lower ride height
• Will NOT fit Raptor models
• Maximum 5.5" backspacing wheels recommended due to wheel/tire clearance to the UCAs
• This kit will not work on trucks with a stock ride height over 22". FX4, Snow Prep, and other off-road packages may have a stock ride height over 22"
