Configured with Large Bore knuckles (required for factory 22" wheel bearing assemblies, build codes WPM or WPZ) and a Strut Spacer / FOX Adventure Series shock package. Front lift is achieved via cross member and strut spacer (4"); rear lift via coil spring (3"). Total adjustable lift range: 4–5.5".
Overview
The Zone Offroad 4" IFS Lift System is designed specifically for the 2025+ Ram 1500 4WD to improve stance and provide clearance for larger tires. These kits are manufactured in the USA and are backed by Zone Offroad's Factory Protection Plus program, which includes a Limited Lifetime Warranty, ESC system compatibility, and a 5-year/100,000-mile drivetrain warranty.
Features
- Corrects suspension, steering, and driveline geometry for improved on-road handling and off-road performance
- Heavy-duty differential skid plate improves off-road protection
- High-strength, CNC machined replacement steering knuckles improve strength while correcting steering angles
- Top mount strut and preload spacers set ride height and maintain ride quality
- Rear coil springs achieve a leveled stance while maintaining ride quality and load capacity
- Manufactured in the USA
- Backed by Factory Protection Plus: Limited Lifetime Warranty, ESC system compatibility, and 5-year/100,000-mile drivetrain warranty
Specifications
- Front Lift Height: 4"
- Rear Lift Height: 3"
- Total Adjustable Lift Range: 4–5.5"
- Rear Lift Method: Coil Spring
- Shocks Included: Yes
Installation
- Estimated Time: 8 hours
- Difficulty: Moderate
- Special Tools Required: Strut Compressor
Important Notes
- Fits models with 3.0L Hurricane I6, 3.6L V6, and 5.7L V8 engines.
- Will NOT fit 2019–2024 RAM 1500 Classic models. Refer to the 2018 kit listings.
- Will NOT fit models equipped with the Thermal Axle option (build code DSK-P).
- Vehicles equipped with the Off-Road Group option require special steps similar to the Ram 1500 Rebel. To determine if your truck has the Off-Road Group, contact your local Ram dealer with your VIN and request your window sticker. Look for "Off-Road Group" under the "Optional Equipment" section.
- RAMs with factory 22" wheels require the Large Bore knuckle variant due to a larger wheel bearing assembly (build codes WPM or WPZ).
- Stock 18" wheels cannot be reinstalled due to steering interference. Stock 20" and 22" wheels can be reinstalled with factory tire size.
- This kit will NOT work on Diesel models.
- Does NOT work on models with factory airbag suspension.
- Disconnect BOTH batteries (Main and Auxiliary, if equipped) before performing the install. See instructions for full detail.
- Bumper Spacer Kit (ZOND5802) recommended for additional tire-to-fender clearance. Sold separately.
- IF USING 18" AFTERMARKET WHEELS WITH 4.5" BACKSPACING, TEST FIT WHEELS ON VEHICLE BEFORE MOUNTING TIRES TO ENSURE CLEARANCE.
