Select this option if your 2021-2026 Ford F150 does not have a ride height sensor mounted on the upper control arms. If you are unsure whether your truck is equipped with Adaptive Headlights, inspect your upper control arms for a sensor — if none is present, this is the correct configuration for your vehicle.
Overview
This 2.5 inch performance leveling system from BDS Suspension is designed for 2021-2026 Ford F150 4WD trucks. The kit levels the factory stance from front to rear while providing clearance for up to 35-inch tires. Up front, the kit includes FOX Factory Race Series 3.0 Internal Bypass (IBP) coil-over shocks paired with heavy-duty tubular upper control arms for increased strength and improved geometry. The rear is equipped with matching FOX Factory Race Series 3.0 IBP shocks. The kit installs with 100% bolt-on fitment and is compatible with Blue Cruise.
Features
- Front FOX 3.0 Factory Race Series Internal Bypass coil-overs for position-sensitive damping and Dual Speed Compression (DSC) adjustment
- Rear FOX 3.0 Factory Race Series Internal Bypass shocks for improved ride quality, performance, and capability
- HD tubular upper control arms constructed from 1.5" OD x .120-wall tubing with indexed ball joint cup for corrected ball joint positioning, additional down travel, and camber adjustment
- Upper control arms feature durometer-specific rubber bushings at frame mounts and greaseable ball joints at the outer end
- Upper control arms finished in durable black powder coat with billet aluminum dust cap
- Adjustable height to fine-tune lift
- Provides a level stance from front to rear
- Clearance for up to 35-inch tires
- 100% bolt-on installation
- FOX shocks are fully serviceable and resistant to corrosion and harsh environments
- Compatible with Blue Cruise
FOX 3.0 Factory Race Series Internal Bypass Shocks
- Patented Internal Bypass technology provides multiple zones of damping control
- Position-sensitive damping delivers a comfortable ride in normal conditions with increased damping force through rough terrain
- Controls hard bottom-outs, prevents harsh top-outs, and provides an initial catch for landings
- Dual Speed Compression (DSC) adjuster allows tuning for load, environment, and driving style
- Finned external reservoirs and aluminum shock bodies dissipate heat for consistent performance
- Type III anodization on 3-inch diameter bodies prevents corrosion and wear
Specifications
- Lift Height: 2.5 inches
- Front shocks: FOX Factory Race Series 3.0 Internal Bypass coil-overs
- Rear shocks: FOX Factory Race Series 3.0 Internal Bypass shocks
- Upper control arm tubing: 1.5" OD x .120-wall
- Tire clearance: Up to 35 inches
- Application: 2021-2026 Ford F150 4WD
Installation
- Estimated Time: 3–4 hours
- Difficulty: Moderate
- Special Tools Required: Ball Joint Separation Tool
Important Notes
- Models with the Adaptive Headlights option that have a sensor on only the driver's side upper control arm are compatible with the appropriate kit variant. This kit will NOT fit models with sensors mounted on both front upper control arms.
- Will NOT work with trucks equipped with CCD (Continuous Controlled Damping).
- Will NOT work with Diesel models.
- Not compatible with trucks equipped with the On-Board Scales option.
- Will NOT work with the Raptor model.
- Recalibration of your vehicle's Advanced Driver Assistance System (ADAS) cameras, radars, light detection and ranging (LiDAR), and other sensors may be necessary by your local dealership or ADAS service center. This will ensure proper functionality of features such as lane keeping, lane departure, parking assistance, blind-spot detection, adaptive cruise control, and other functions as they operated prior to installation. Please connect with your local dealership or ADAS service center.
- Similar to a wheel alignment, all charges and expenses that may occur from dealership calibrations and adjustments are the sole responsibility of the vehicle owner.
